Coiled spiral powered USB 24V cable Product introduction

POWEREDUSB uses a more complex connector than standard USB, maintaining the standard USB 1.x/2.0 interface for data communications and adding a second connector for power. Physically, it is essentially two connectors stacked such that the bottom connector accepts a standard USB plug and the top connector takes a power plug. Powered USB plugs have POWEREDUSB 5V, POWEREDUSB 12V, POWEREDUSB 24V, POWEREDUSB 1X8, POWEREDUSB 2X4 etc connector. This product is POWEREDUSB 24V male to male cable, It is a standard POWEREDUSB connection. The wire of the cable is TPU shell with coiled spiral shape, the conductor of the wire is 1PX28AWG+6CX20AWG+AL（25% coverage）+GND（28AWG）+36AWG Braid（85% coverage）. The Red 24 volt plugs should never be plugged in or removed with the unit powered on. This is likely to cause the failure of the jack.

Product specification

Product Name	Coiled spiral powered USB 24V cable
Type	POS, Printer and scanner cable
Length	Up to 3.0 meter
Feature	Spring shape wire
Wire	Standard powered usb wire
packaging	PE bag

Powered USB history;

PoweredUSB, as a proprietary variant of USB, was developed and proposed by IBM, Berg (now FCI), NCR and Microsoft between 1998 and 1999, with the last revision (0.8g) issued in 2004. The specification is not endorsed by the USB Implementers Forum (USB-IF).IBM, who owns patents to PoweredUSB, charges a licensing fee for its use.

PoweredUSB was licensed by Hewlett-Packard, Dell Inc., Cyberdata, Fujitsu, Wincor and others.
