USB A to 2.54mm 5 pin cable Details :
· Left side Connector Pitch 2.54mm 5pin Dupont
· Right side Connector USB A Male
· Length 15CM to 50CM
· Conductor Pure Copper
· Insulation PVC
· House ABS or nylon
· Terminal Gold plated
USB 2.0 A Female to Pitch 2.54mm 5pin cable Dupont connector pin assignment
RED VCC – first pin
WHITE D- – second pin
GREEN D+ – third pin
BLACK Ground – fourth pin
Shield Braided – fifth pin
Technical Requirement:
1.100% open and short test.
2.Insulation resistance:5MΩ/Min
connect resistance:1Ω/Max
3.Test voltage DC 300V at 10ms
How does your quality guarantee?
We have 100% quality guarantee to customers. We will be responsible for any quality problem.
From first sample to mass production, we check the drawing sample and testing in accordance.
Can we visit your factory before place the order?
Yes, Warmly welcome that must be nice to set up good relationship for business. And then you can know our factory more with quality control, design ability, machines production ability etc.
Also if you need us to pick up at airport or high speed train station, we can help.
For some reason if you need invitation letter, we also can help you to get approval.
Would you have a discount if l have a large order USB 2.0 A Female to Pitch 2.54mm 5pin cable ?
Yes we could offer different discount according to your order quantity. Usually more bigger order have more discount.
