USB A M to angle 2.5mm audio cable Details
· Connector 1 2.5mm 2 Pole audio
· Connector b USB A male
· Length 10CM to 100CM
· Conductor Copper 26awg or 28awg*2
· Insulation PVC
· Color Black
· Packing Single PE bag
USB A M to angle 2.5mm audio cable pin out:
RED VCC – Tip
BLACK Ground – Ring
Technical Requirement:
1.100% open and short test.
2.Insulation resistance:5MΩ/Min
connect resistance:1Ω/Max
3. Test voltage DC 300V at 10ms
This cable is suitable for massages, electrode, pod, pulse devices to use, usually the current requires very small and room is limited, then you can design this 2.5mm female audio port to cooperate with this
Cable, as USB A is very common and easy to get the power, so you can cost down and make the design
Very simple and very easy to carry. This is why this cable is very popular used at those locations.
Our clients:
Payment metholds:
Shipping methods:
USB A male to 2.5mm stereo jack audio cable:
This USB A to 2.5mm stereo jack cable has only 2 cores for connections between USB A male and 2.5mm mono audio jack, so the cable has only one fucntion which is power supply or data transfer. power supply connection is VCC and GND pins, data transfer connection is D+ and D- pins.
if you want the cable have power supply and data transfer same time, the plug of 2.5mm mono jack should be changed to 4 poles.
